Dudek Hadron 1.1 Paraglider

$3,300.00

The Dudek Hadron 1.1 is dedicated for the frequent and experienced flyers, who have perfectly mastered the reflex glider specifics.

Want to Learn More About The Hadron 1.1?

Description

Dudek Hadron 1.1 Paraglider For Paramotor & Powered Paragliding Buy Online

The Hadron 1.1 by Dudek Paragliders:

FROM THE MANUFACTURER: “Hadrons are tiny elementary particles, which speed up can carry gigantic amounts of energy. Accordingly, the Hadron is fast, energetic and can lift a lot.

The paraglider is dedicated for the frequent and experienced flyers, who have perfectly mastered the reflex glider specifics.
Hadron’s “reflexivity” is constant in all trimmer positions. At 5,9 aspect ratio its 59 cells look relatively modest, allowing for easy inflation and perfect internal pressure distribution. Synthetic rods on its leading edge bring considerably better launch characteristics and stability at high speeds.

Serial produced Hadrons are equipped with 2D steering system, similar to classic steering configuration (the pilot has but two brakes at his disposal). Steering is designed so that at low and medium speeds the steering lines geometry is not very aggressive, thus enhancing precise canopy control. At high speeds (full trims + speedbar) only the outer steering lines should be used, alternatively you can make some corrections by the TEA/TST system.
Since the steering is divided, an experienced pilot can adjust brake progression to his own liking. The other systems known from our previous canopies (ALC or TST) can be used too, without much trouble at installation. Everything depends on experience and creativity of the pilot. When flying this class of paragliders, they are usually abundant and pilots can tune steering to their style.

Like all of our paragliders, Hadron is produced entirely in Europe, at our Polish plant. Thus close monitoring of the complicated production process is possible, and the distance between designer’s ideas and their implementation is as short as it can be. Additionally, Hadron is the first paraglider we cut exclusively with a recently purchased state-of-the-art laser cutter. Stunning capabilities of this machinery allow for serial cutting of intricately shaped, narrow parts in large numbers, as well as their best distribution regarding the textile structure. Without such precise technology at our disposal, production of the Hadron would simply not be possible.”

INCLUDES:

  • MotoBag XX (backpack for tight canopy packing, without harness)
  • DewBag (quickpack)
  • Transport bag including compression strap.
  • speedbar Easy Catch
  • pouch with documents and repair kit (self-adhesive cloth, spare line)
  • wind ribbon and windsock
  • small gifts

SPECS (from Dudek’s website):

Dudek Hadron Sizes: 18 20 22 24
Approval – ULM identification yes yes yes yes
Number of cells 59 59 59 59
Surface area (flat) [m2] 18 20,00 22,00 24,00
Surface area (projected) [m2] 15,62 17,36 19,1 20,83
Span (flat) [m] 10,30 10,86 11,39 11,9
Span (projected) [m] 8,32 8,78 9,21 9,61
Aspect ratio (flat) 5,90
Aspect ratio (projected) 4,44
Sink [m/s] min = 1.2 +/- 0.2
Speed [km/h] min = 24 ; trim = 38-51 ; max = 62 (+/- 3)
Distance pilot to win [m] 6,60 7.01 7.34 7.67
Total lines lenght [m] 316 335 351 368
Total take-off weight [kg] 70-100 80-110 85-120 95-135
Max take-off weight – competition [kg] 110 120 140 160
Distance between risers [cm] 45 45 45 45
Load test [kg] 1179
Weight of the wing [kg] 4.7 5.2 5.6 5.8
Lines Edelrid A-8000U: 050 / Liros TSL: 090 & 140 & 190 & 280
Fabric Porcher 38g / Porcher Hard 40g / Dominico Tex 34g / SR Scrim / SR Laminate 180g

()* Maximum allowable take-off weight for very experienced pilots. CAUTION: the paraglider considerably alters its behavior depending on the wing load. Maximum loads require employing highest pilot skills.

** DGAC certificate is based on flight test and internal paramotor flight tests. It is compulsory in France and regarded as reliable in ever growing number of countries.

COLOR OPTIONS:

Dudek Hadron 1.1 Paraglider COLOR OPTIONS


(Click Images to Enlarge)

NEED HELP DECIDING THE CORRECT SIZE GLIDER?

CONTACT US: (209) 786-7899
